Fully stainless steel structure
Hand wheel type of quick-open door structure
Door safety lock system
Digital display of working status, touch of key
Self-inflating type seal
Over temperature&over pressure auto-protection
Safe protection of water lacking
Automatically shut off with beep reminding after sterilization
Auto discharge the cool air and steam discharging automatically after sterilization
Used for sterilization of medical instruments, medical cotton products
Fully stainless steel SUS304/AISI 304 -3mm
24 months warranty
Possible to install drying system according to request
| Model | SV-28HD | SV-35HD | SV-50HD | SV-75HD | SV-100HD |
|---|---|---|---|---|---|
| Capacity | 28L (φ270*500)mm | 35L (φ318*450)mm | 50L (φ340*550)mm | 75L (φ400*600)mm | 100L (φ440*650)mm |
| Working pressure | 0.22Mpa | ||||
| Working temperature | 134°C | ||||
| Max.working pressure | 0.23Mpa | ||||
| Heat average | ≤±1°C | ||||
| Timer | 0~99min or 0~99hours59 min | ||||
| Temp.range | 105°C~134°C | ||||
| Power | 2KW/AC220V.50Hz | 2.5KW/AC220V.50Hz | 3KW/AC220V.50Hz | 4.5KW/AC220V.50Hz | |
| Exterior size | 400*370*700mm | 450*450*1010mm | 510*470*1130mm | 560*560*1120mm | 540*560*1250mm |
| Packing size | 440*320*750mm | 570*550*1150mm | 590*590*1280mm | 650*630*1280mm | 680*630*1370mm |
| G.W/N.W | 26/23kg | 72/56kg | 88kg/68kg | 100kg/80kg | 110kg/85kg |
